Digital pH Sensor Series
Product Name: Digital pH Sensor
Product model: CS1700D
Product brand：FLUIDINGS
Power supply voltage: 9-36VDC
CS1700D digital pH sensor is suitable for general industrial processes, with double salt bridge design, double-layer water seepage interface, and resistance to medium reverse seepage. The ceramic pore parameter electrode oozes out of the interface, which is not easy to be blocked, and is suitable for the monitoring of common water
quality environmental media. Adopt PTFE large ring diaphragm to ensure the durability of the electrode; Application industry: supporting agricultural water and fertilizer machine.
Features
Round bulbs, large sensitive areafast response, stable signal。
PP material,Work well at 0~60℃.
3.The lead is made of pure copper, which can directly realize remote transmission,
which is more accurate and stable than the lead signal of copper-zinc alloy.
| Parameter | Configuration |
| pH Range | 2-12pH |
| pH Zero | 7.00±0.25 |
| Temp Range | 0-80℃ |
| Output Signal | RS485&4-20mA |
| Pressure Range | 0—0.3MPa |
| Temperature Sensor | None |
| Housing Materials | PA+GF |
| Membrane Resistance | ＜500MΩ |
| Reference System | Ag/AgCl/KCl |
| Liquid Junction | Ceramic Cores |
| Electrolyte Solution | KCl |
| Double Salt Bridge | Yes |
| Threaded connection | NPT3/4’’ |
| Cable Length | 2m or Customize |
| Wire Connection | Pin, BNC or Customize |
application area
safety
environmental protection
oil
chemical
pharmaceutical
metallurgy
coal chemical industry
