Digital pH Sensor Series
Product Name: Digital pH Sensor
Product model: CS1753AD
Product brand：FLUIDINGS
Power supply voltage: 9-36VDC
CS1753AD digital pH sensor comes with RS485 and 4-20mA output, the standard cable is 10 meters. Double salt bridge design, double-layer water seepage interface, resistant to medium reverse seepage. The ceramic pore parameter electrode seeps out of the interface and is not easy to be blocked. High-strength glass bulb design, the glass appearance is more sturdy. Large sensing bulbs increase the ability to perceive hydrogen ions and perform well in complex
environments.The electrode material PP has high impact resistance, mechanical strength and toughness, and is resistant to a variety of organic solvents and acid and alkali corrosion. Digital sensor, strong anti-interference ability,high stability and long transmission distance.
Features:
1. PP material，Work well at 0~60℃
2. Round bulbs, large sensitive area fast response, stable signal
3.The lead is made of purecopper, which can directly realize remote transmission,
which is more accurate and stable than the lead signal of copper-zinc alloy.
| Parameter | CS1753AD |
| pH Range | 0- 14pH |
| pH Zero | 7.00±0.25 |
| Temp Range | 0-80℃ |
| Output Signal | RS485 or 4-20mA |
| Pressure Range | 0—0.6MPa |
| Temperature Sensor | NTC10K |
| Housing Materials | PP, Glass/Silver, SNEX |
| Membrane Resistance | ＜500MΩ |
| Reference System | Ag/AgCl/KCl |
| Liquid Junction | Ceramic Cores |
| Electrolyte Solution | AgCl |
| Double Salt Bridge | Yes |
| Threaded connection | NPT3/4’’ |
| Cable Length | 10m or Customize |
| Wire Connection | Pin, BNC or Customize |
application area
safety
environmental protection
oil
chemical
pharmaceutical
metallurgy
coal chemical industry
