Digital ISE Sensor Series CS6710AD
Product Name: Digital ISE Sensor Series
Product model: CS6710AD
Product brand：FLUIDINGS
Power supply voltage: 9-36VDC
CS6710AD digital fluoride ion sensor uses a solid membrane ion selective electrode for testing fluoride ions floating in water, which is fast, simple, accurate and economical.The design adopts the principle of single-chip solid ion selective electrode, with high measurement accuracy. Double salt bridge design, longer service life.The patented fluoride ion probe, with an internal reference fluid at a pressure of at least 100KPa (1Bar), seeps extremely slowly from the microporous salt bridge. Such a reference system is very stable and the electrode life is longer than the ordinary.
Features:
1.large sensitive area fast response, stable signal
2.PP material，Work well at 0~50℃。
3.The lead is made of pure copper, which can directly realize remote transmission, which is more accurate and stable than the lead signal of copper-zinc alloy.
| Parameter | CS6710AD |
| Measured Range | 0~1000mg/L(Customizable) |
| Principle | Ion selective sensor |
| Temp Range | 0-50℃ |
| Output Signal | RS485 or 4-20mA |
| Pressure Range | 0—0.1MPa |
| Temperature Sensor | NTC10K |
| Housing Materials | PP+PVC |
| Membrane Resistance | ＜500MΩ |
| Calibration | Standard liquid calibration |
| Accuracy | ±2.5% |
| Resolution | 0.1mg/L |
| Connection method | 4 or 6 core cable |
| Threaded connection | NPT3/4’’ |
| Cable Length | 10m or Customize |
| Wire Connection | Pin, BNC or Customize |
application area
safety
environmental protection
oil
chemical
pharmaceutical
metallurgy
coal chemical industry
