CS6711AD Digital ISE Sensor Series

Product Name: Digital ISE Sensor Series

Product model: CS6711AD

Product brand:FLUIDINGS

Power supply voltage: 9-36VDC

CS6711AD digital fluoride ion sensor uses a solid membrane ion selective electrode for testing fluoride ions floating in water, which is fast, simple, accurate and economical.The design adopts the principle of single-chip solid ion selective electrode, with high measurement accuracy. Double salt bridge design, longer service life.The patented fluoride ion probe, with an internal reference fluid at a pressure of at least 100KPa (1Bar), seeps extremely slowly from the microporous salt bridge. Such a reference system is very stable and the electrode life is longer than the ordinary.


DESCRIPTION

Features:


1.large sensitive area fast response, stable signal

2.PP material,Work well at 0~50℃。

3.The lead is made of pure copper, which can directly realize remote transmission, which is more accurate and stable than the lead signal of copper-zinc alloy.


ParameterCS6711AD
Measured   Range0~1000mg/L(Customizable)
PrincipleIon selective sensor
Temp Range0-50℃
Output   SignalRS485 or 4-20mA
Pressure Range0—0.1MPa
Temperature SensorNTC10K
Housing MaterialsPP+PVC
Membrane Resistance<500MΩ
CalibrationStandard liquid calibration
Accuracy±2.5%
Resolution0.1mg/L
Connection method4 or 6 core cable
Threaded connectionNPT3/4’’
Cable Length10m or Customize
Wire ConnectionPin, BNC or Customize



application area

safety

environmental protection

oil

chemical

pharmaceutical

metallurgy

coal chemical industry

storage
